EFS Elite Lift Kit to suit Toyota Surf 185 AND 90 Series Prado 1996 – 2003 40mm

This is a suspension lift kit to jack up your Toyota Surf 185 1996 to 1997 by 2 inches (40MM) keeping it within the legal limit.

Designed for harsh conditions and rugged terrains without compromising comfort. Powered by EFS suspension, this is one of the best kits you can get for on and off-roading.

What you get in the kit

• Pair of front EFS Elite shocks (Part No. 38-5636)
• Pair of front EFS Coils (Part No. TPR-101*)
• Pair of rear EFS Elite shocks (Part No. 36-5581)
• Pair of rear EFS Coils (Part No. TPR-103*)
• 3 year / 100,000 km warranty

NOTE: For 1998 models (rare in 1997) coil spacers are required to keep rear coil captive due to different coil pattern. Please add to your cart if required, please see Part No. 9182

About the shocks

EFS is built with high quality internal & external components combined together to give you excellent performance and longevity.

EFS shock absorbers are vehicle & height specific with valving developed to suit each vehicle. Not a one shock suits all approach

• 51mm 60mm External Tube Greater oil capacity to keep the valve at a lower operating temperature
• Low Pressure Nitrogen Gas Prevent the oil from cavitating (foaming)
• Long Travel Design Maximises wheel articulation
• 35mm Piston, Twin Tube Construction Increased control of the spring during rebound and compression cycles
• 16mm Quality Hardened Chromed Piston Rod Longer service life, and greater lateral strength
• 1.5mm Outer & Inner Wall Thickness Greater durability and strength
• Dynamic Motion Control Valve Adjusts to different road & off road conditions
• Vehicle and height specific valving Specifically designed and developed to suit each vehicle
• High quality internal and external components Prevents fade under harsh conditions and includes long life polyurethane bushes

About the coils

EFS have a broad range of coil springs to accommodate your vehicles needs from standard height to 125mm.

Coil springs for towing, load bearing, comfort, increased ride height and competition.

All EFS Coil Springs are:

• Shot Peened To stress relieve the outer surface of the Coil, so the Coil can operate under higher fatigue & repeated load conditions to ensure longevity.
• Scragged for Quality Control This is a process where the Coil is compressed beyond its yield point; this compression will set-up residual stresses and increase the elastic limit of the spring.
• Powder Coated To resist corrosion & to protect the spring steel from minor damage.
• 602i2Mn Steel High quality spring steel with high carbon content and durable elastic properties.

Linear rate and progressive rate coils are available.
